µ-Dish 35 mm, high Grid-500

SKU: IB-81166 UNSPSC: 41122107 Manufacturer Part No: 81166 Pack Size: 60
  • Ideal for locating cells or cell clusters
  • Unique ibidi Polymer Coverslip combining
    • Excellent cell culture conditions; and
    • Supreme optical quality for high resolution microscopy
  • Ideal cell growth conditions provided by the ibiTreat surface
  • Lid with lock position, which minimizes evaporation
  • Suitable for DIC, when used with the special DIC Lid
Special Requirements?

Build out your order then request a quote from your cart.

Price: £173.00 ex. VAT

VAT
Ex. Inc.

A 35 mm imaging dish with an ibidi Polymer Coverslip bottom, high walls, and an imprinted 500 µm cell location grid

  • Ideal for locating cells or cell clusters
  • Unique ibidi Polymer Coverslip combining
    • Excellent cell culture conditions; and
    • Supreme optical quality for high resolution microscopy
  • Ideal cell growth conditions provided by the ibiTreat surface
  • Lid with lock position, which minimizes evaporation
  • Suitable for DIC, when used with the special DIC Lid

Applications

  • Relocating cells or cell clusters, e.g., transfected cells for clone picking
  • Counting events per defined area (e.g., for calculating transfection efficiency)
  • Providing a reference structure for cell movements
  • Treatment of distinct single cells, such as in microinjection
  • Following axon growth on a defined scale bar

Technical Features

  • Standard format dish with a 35 mm diameter
  • Grid with a 500 µm repeat distance
  • Lettered and numbered fields (A-U; 1-20)
  • Also available with a glass bottom: µ-Slide 35 mm, high glass bottom with Grid-50 or with Grid-500
  • Ideal cell growth conditions provided by the ibiTreat tissue culture treated surface
  • Made of biocompatible material using no glues, consequently no cells are harmed
  • Lid with lock position, which minimizes evaporation
  • Grid-500 also available in a µ-Slide 8 Well version

Specifications Table

Grid repeat distance500 µm
Ø µ-Dish35 mm
Volume2 ml
Growth area3.5 cm2
Coating area using 400 µl4.1 cm2
Ø observation area21 mm
Height with lid14 mm
Bottom: ibidi Polymer Coverslip
Grid repeat distance500 µm
Ø µ-Dish35 mm
Volume2 ml
Growth area3.5 cm2
Coating area using 400 µl4.1 cm2
Ø observation area21 mm
Height with lid14 mm
Bottom: ibidi Polymer Coverslip
Variant
Pack/Size
Ordering
Price
Qty
8116X_Dish_35mm_high_Grid500_RGB_Icon
µ-Dish 35mm, high Grid-500 ibiTreat: Ø 35mm, high wall (2ml), 500 µm grid, #1.5 polymer coverslip, sterilized
60 / Pack

SKU: IB-81166

Manufacturer Part No: 81166

UNSPSC Code: 41122107

Price: £173.00 ex. VAT
