µ-Slide 2 Well Co-Culture


Key Features

A µ-Slide (chambered coverslip) suitable for co-cultivation assays in combination with microscopy

  • Cells share soluble factors but grow separately
  • Possesses low evaporation properties and is thus suitable for long-term assays
  • Has excellent optical quality and is therefore suitable for fluorescence microscopy

SKU: N/A Categories: ,
Special Requirements?



  • Co-cultivation of different cell lines or primary cells
  • Mesenchymal-epithelial interactions
  • Paracrine interaction of different cell populations in vitro
  • Cell or spheroid culture in gel matrices

Technical Features:

  • Two major wells each with 9 minor wells
  • Cells share soluble factors but grow separately


Number of major wells2
Dimensions of major wells
(w x l x h) in mm
21.5 x 23.6 x 6.8
Volume per major well600 µl
Number of minor wells2 x 9
Dimensions of minor wells
(w x l x h) in mm
6.1 x 6.8 x 1.3
Volume of each minor well70 µl
Growth area per minor well0.4 cm2
Coating area per minor well0.55 cm2
Total height with lid8 mm
Bottom: ibidi Polymer Coverslip

Define and print your experimental setup

Seeding Cells

Step 1:

Seed 60 µl of recipient cells in the
inner reservoir.

Step 2:

Seed 60 µl of the feeder cells in the
outer reservoirs.
Await cell attachment; aspirate all
unattached cells and medium.

Step 3:

Overlay each major well with 600 µl cell free medium.

Detailed Cross Section with Indicated Conditioned Medium

    Additional information


    Uncoated, ibiTreat


    ibidi Polymer
