omniPAGE Mini, 10 x 10cm Vertical Electrophoresis System

£386.00£523.00

Key Features

Use OmniPAGE mini vertical systems to:

  • Run a maximum of 4 gels within an hour
  • Perform 2-D and blotting within a day
  • Undertake discovery projects
  • Screen new samples and evaluate sample preparation conditions
Clear
VS10
Special Requirements?

Description

Cleaver Scientific Mini Vertical systems are predominantly used for protein electrophoresis. They include the OmniPAGE CVS10TETRAD systems equipped with enough combs and glass plates to run 4 gels, and the standard OmniPAGE CVS10 systems, which accommodate up to 2 handcast or commercial precast gels.

By combining both functionality and ease of use, the OmniPAGE CVS10TETRAD and standard OmniPAGE CVS10 systems set the bench mark for simple, versatile vertical mini gel electrophoresis. Each OmniPAGE electrophoresis system can accommodate up to 4 handcast gels and 2 commercial precast gels to provide complete flexibility for individual research needs, while unique sliding clamp technology within the PAGE insert facilitates fast, intuitive leak-free casting.

With a trouble-free set up and consistent performance, the OmniPAGE Mini Vertical systems are perfect for today’s laboratories, where the ability to generate reproducible results quickly is essential.

Number of gels 1-4
Precast gel compatibility (Up to 2 gels/run) IDGel, Novex, SERVAGel, Thermo Precise Pierce Protein Gel
Plate dimensions (w x h x t) 10x10x0.2cm
Gel Dimensions (w x h) 8x8.5cm
Total buffer Volume for 2 gels Min: 250ml; Max: 1200ml
Total buffer Volume for 4 gels Min: 250ml; Max: 1200ml
Standard run time for SDS-PAGE 1-2 hours at from 90-225V
Recommended power supplies NanoPAC-300; CS-300V; CS-3AMP for blotting
Unit Dimensions (w x d x h) 19x13x15cm
Weight 1.8Kg

Additional information

Including Caster

No, Yes

Includes Combs and Plates

No, Yes

Includes Additional Caster

No, Yes

Accessories…

Placeholder
EXTERNAL CASTING STAND – NO CASTING BASE
CVS10EXCASTER
Placeholder
EXTERNAL CASTING SYSTEM – UPSTAND+ BASE
CVS10EXCASTERSYS
Placeholder
omniPAGE Mini, 10 x 10cm Dual Caster.
VS10DCAST
Placeholder
Replacement Rubber mats for 10 x 10cm caster.
VS10DCASTM
Placeholder
omniPAGE Mini – Inner Running Module. CLAMP VERSION
CVS10DIRM
Placeholder
Mini Cooling Block.
VS10ICB
Placeholder
10 x 10cm Notched Glass Plates 2mm thick ( Pack of 2)
VS10NG
Placeholder
10 x 10cm Plain Glass Plates 2mm thick ( Pack of 2)
VS10PG
Placeholder
10 x 10cm Plain Glass Plates with 0.5mm Bonded Spacers (Pack of 2)
VS10PGS0.5
Placeholder
10 x 10cm Plain Glass Plates with 0.75mm Bonded Spacers (Pack of 2)
VS10PGS0.75
Placeholder
10 x 10cm Plain Glass Plates with 1mm Bonded Spacers ( Pack of 2)
VS10PGS1
Placeholder
10 x 10cm Plain Glass Plates with 1.5mm Bonded Spacers (Pack of 2)
VS10PGS1.5
Placeholder
10 x 10cm Plain Glass Plates with 2mm Bonded Spacers (Pack of 2)
VS10PGS2
Placeholder
10 x 10cm Notched Glass Plates with 0.5mm Bonded Spacers (Pack of 2)
VS10NGS0.5
Placeholder
10 x 10cm Notched Glass Plates with 0.75mm Bonded Spacers (Pack of 2)
VS10NGS0.75
Placeholder
10 x 10cm Notched Glass Plates with 1mm Bonded Spacers ( Pack of 2)
VS10NGS1
Placeholder
10 x 10cm Notched Glass Plates with 1.5mm Bonded Spacers (Pack of 2)
VS10NGS1.5
Placeholder
10 x 10cm Notched Glass Plates with 2mm Bonded Spacers (Pack of 2)
VS10NGS2
Placeholder
Dummy Plate, 10 x 10cm
VS10DP
Placeholder
10cm Spacers – 0.5mm (Pack of 2)
VS10S0.5
Placeholder
10cm Spacers – 0.75mm (Pack of 2)
VS10S0.75
Placeholder
10cm Spacers – 1mm thick (Pack of 2)
VS10S1
Placeholder
10cm Spacers – 1.5mm thick (Pack of 2)
VS10S1.5
Placeholder
10cm Spacers – 2mm thick (Pack of 2)
VS10S2
Placeholder
Comb 1 Prep, 1 Marker, 0.5mm thick
VS10-1-0.5
Placeholder
Comb 5 sample, 0.5mm thick
VS10-5-0.5
Placeholder
Comb 8 sample MC, 0.5mm thick
VS10-8MC-0.5
Placeholder
Comb 9 sample, 0.5mm thick
VS10-9-0.5
Placeholder
Comb 10 sample, 0.5mm thick
VS10-10-0.5
Placeholder
Comb 12 sample, 0.5mm thick
VS10-12-0.5
Placeholder
Comb 16 sample MC, 0.5mm thick
VS10-16MC-0.5
Placeholder
Comb 20 sample, 0.5mm thick
VS10-20-0.5
Placeholder
Comb 1 Prep, 1 Marker, 0.75mm thick
VS10-1-0.75
Placeholder
Comb 5 sample, 0.75mm thick
VS10-5-0.75
Placeholder
Comb 8 sample MC, 0.75mm thick
VS10-8MC-0.75
Placeholder
Comb 9 sample, 0.75mm thick
VS10-9-0.75
Placeholder
Comb 10 sample, 0.75mm thick
VS10-10-0.75
Placeholder
Comb 12 sample, 0.75mm thick
VS10-12-0.75
Placeholder
Comb 16 sample MC, 0.75mm thick
VS10-16MC-0.75
Placeholder
Comb 20 sample, 0.75mm thick
VS10-20-0.75
Placeholder
Comb 1 Prep, 1 Marker, 1mm thick
VS10-1-1
Placeholder
Comb 5 sample, 1mm thick
VS10-5-1
Placeholder
Comb 8 sample MC, 1mm thick
VS10-8MC-1
Placeholder
Comb 9 sample, 1mm thick
VS10-9-1
Placeholder
Comb 10 sample, 1mm thick
VS10-10-1
Placeholder
Comb 12 sample, 1mm thick
VS10-12-1
Placeholder
Comb 16 sampl MC, 1mm thick
VS10-16MC-1
Placeholder
Comb 20 sample, 1mm thick
VS10-20-1
Placeholder
Comb 1 Prep, 1 Marker, 1.5mm thick
VS10-1-1.5
Placeholder
Comb 5 sample, 1.5mm thick
VS10-5-1.5
Placeholder
Comb 8 sample MC, 1.5mm thick
VS10-8MC-1.5
Placeholder
Comb 9 sample, 1.5mm thick
VS10-9-1.5
Placeholder
Comb 10 sample, 1.5mm thick
VS10-10-1.5
Placeholder
Comb 12 sample, 1.5mm thick
VS10-12-1.5
Placeholder
Comb 16 sampl MC, 1.5mm thick
VS10-16MC-1.5
Placeholder
Comb 20 sample, 1.5mm thick
VS10-20-1.5
Placeholder
Comb 1 Prep, 1 Marker, 2mm thick
VS10-1-2
Placeholder
Comb 5 sample, 2mm thick
VS10-5-2
Placeholder
Comb 8 sample MC, 2mm thick
VS10-8MC-2
Placeholder
Comb 9 sample, 2mm thick
VS10-9-2
Placeholder
Comb 10 sample, 2mm thick
VS10-10-2
Placeholder
Comb 12 sample, 2mm thick
VS10-12-2
Placeholder
Comb 16 sample MC, 2mm thick
VS10-16MC-2
Placeholder
Comb 20 sample, 2mm thick
VS10-20-2
Placeholder
VS10 Silicone Gasket (PK/1)
VS10SG
Placeholder
VS10 lid (No cables)
VS10LID
Placeholder
VS10 Tank
VS10TANK
